Description

-Automatic Voltage Regulation circuit (AVR)
-Output sockets for blackout protection
-Output sockets for overvoltage protection
-Cold start function
-Compatible generators
-LCD display (power line status and residual backup time)

Nominal Input Voltage:110/120Vac or 220/230/240 Vac
Operating Voltage Range: 81-145Vac/162-290 Vac
Operating Frequency Range: 50/60 Hz (1±10%)
Output Voltage range (Batt. Mode): Simulated Sinewave at nominal voltage ±10%
Frequency Range (Batt. Mode): 50 Hz or 60 Hz ± 1 Hz
Transfer Time: Typical 2-6 ms, 10ms max.
Typical Recharge Time: 6-8 hours ( To 90% capacity)
Full Protection : Overload and overcharge protection.
Indicators : AC Mode, Battery Mode,Load Level, Battery Level
USB & RS-232 port(Optional) SB or RS232(Supports Windows, 2000/2003/XP/Vista/2008, Windows 7, Linux, Unix, and MAC).
LCD: UPS status, input/output voltage, input/output frequency, load level, battery capacity, and warning or fault error code.
Operating Temperature:0- 40°C
Humidity Range : 0-95 % (Non-condensing)
Noise Level :<45db (1 meter from surface)
