Description

It meets with IEC, JIS, BS, GB/T AND YD/T standards. With advanced AGM valve regulated technology and high purity raw material.

Voltage Per Unit: 12
Cells Per Unit: 6
Nominal Capacity: 9Ah@20hour-rate to 1.75V per cell @25 􁀲
Weight: Approx.: 2.30 Kg (Tolerance± 5.0%)
Internal Resistance Approx: 22 m
Terminal: F1/F2
Max. Discharge Current: 90A (5 sec)
Short Circuit Currentl 450A
Design Life: 6~8 years (Float charging)
Max. Charging Current: 2.1 A
Reference Capacity : 6.96AH, 7.85AH, 8.41AH, 9.00AH
Standby Use Voltage: 13.7 V~13.9 V @ 25℃, Temperature Compensation: -3mV/℃/Cell
Cycle Use Voltage : 14.6 V~14.8 V @ 25℃, Temperature Compensation: -4mV/℃/Cell
Operating temperature Range: Discharge: -20℃~60℃, Charge: 0℃~50℃, Storage: -20℃~60℃
Normal Operating Temperature Range : 25℃± 5℃
Self Discharge:RITAR Valve Regulated Lead Acid (VRLA) batteries can
be stored for up to 6 months at 25℃ and then recharging
is recommended. Monthly Self-discharge ratio is less
than 3% at 25℃ please charge batteries before using
